CE Rohs High Power Integrated Solar Led Street Light Ip65 30w Solar Power Street Light
Advantage of Lithium Battery Solar Street Light
1. Simple design, portable, practical.
2. Powered by solar, saving energy and environmental friendly, its installation is not subject to city grid.
3. Large capacity lithium battery, lifespan about 5-8 years, twice lifespan of the traditional gel battery, lowering the battery maintenance rate of solar street lights.
4. High efficiency of usage during the lithium cycle, avoiding the low efficiency of traditional gel battery after discharge which leads to lack of energy.
5. Integrated lithium battery and controller, no complex assembly work, less wiring connection mistake, making the solar street lights installation easy and simple.
6. No additional wiring is needed, avoiding the mistake of wrong calculation in wiring length and wiring configuration.
7. Lithium battery installed on pole near the lamp, closer distance and less energy lose, ensuring high efficiency of power supply. What’s more, the hanging battery increases the difficulty for vandalism and theft than buried battery underground.
Specifications
| Integrated Solar Led Street Light | |||||
| Power | 16W | 20W | 24W | 30W | 40W |
| Voltage | 12V | ||||
| Capacity of the battery | ≥16AH | ≥20AH | ≥24AH | ≥30AH | ≥40AH |
| LED power | 30*30 SMD | ||||
| LED lamination | 2400LM | 3000LM | 3600LM | 4500LM | 6000LM |
| Inductive components | Microwave sensor | ||||
| The effective distance of the sensor | 6-8M | ||||
| Wireless data transmission | 10M | ||||
| Color of the lamp | White, grey, blue | ||||
| Working temperature range | -20℃~65℃ | ||||
| Working humility range | Lower than 85% RH | ||||
| Storage temperature range | -5℃~35℃ | ||||
| Storage humility range | Lower than 50% RH | ||||
| Working hour | 8H | ||||
| Function of the controller | Over-charging protection, over-discharging protection, short-circuit protection, inverse connection protection, automatic energy-saving mode | ||||
| Cycle life | ≥600 cycles | ||||
| Insulation measure | Foamer | ||||
Specifications for the components
| MINSENS solar street light working mode | 5-13 working hours per day, 2-7 rainy days back-up. |
| Solar Panel | 1. Monocrystalline Solar panel from 30W to 310W, efficiency of more than 18.5% |
| 2. Polycrystalline solar panel from 30W to 270W, efficiency of more than 17.8% | |
| 3. A GRADE high efficient solar panel | |
| 4.Hydrophobic layer with higher light absorption and minimal surface dust | |
| 5. 5 years warranty for solar panels; 20 years power generation capacity | |
| Gel Battery | |
| Lithium Battery | 1. Lifespan:5-8 years, |
| 2. Long service life (3200 cycles @ 30% DOD) | |
| 3. Better Weather-ability (-20 ºC ~ 50 ºC) | |
| 4. Fully sealed construction ,maintenance free long life of up to 5 years | |
| Intelligent Solar Controller, | |
| Lifespan:5-10 years | |
| Intelligent Solar Controller, Lifespan:5-10 years | 1. PWM Type, |
| 2. Over-charging/discharging Protection | |
| 3. Reverse-connection Protection | |
| Light source | 1. Ligh Power LED |
| 2. Lifespan: >80000Hrs, | |
| 3. White Color,140LM/W,30Lux,6500K, IP65,120 Degree Angle, | |
| Pole | 1. Hot-Dip Galvanized, powder coating |
| 2. Lifespan: More than 20 years | |
| 3. Equipped With Arm, Bracket, Flange, Fittings, Cable, | |
| 4. Resistant to Wind: ≥150KM/H |
The above configuration is only for reference and the actual configuration is designed according to the local climate conditions and the customer special requirements.
We promise a guaranteed warranty for the entire system for two years, during which if there is any quality problem found, repair or replacement shall be provided free of charge, and a guarantee for life-long repair.
Details
Traditional Solar Street Light & Integrated Lithium Battery Solar Street Light
| Components Comparison | ||
| Components | Traditional Solar Street Light | Integrated Lithium Battery Solar Street Light |
| Solar Panel | Separated | Separated |
| Battery | Separated | Smart sensor, controller and lithium battery integrated |
| Controller | Separated | |
| Battery Box | Separated | |
| LED Lamp | Separated | |
| Lighting Source | Separated | |
| Cable | Longer, high line lose | Shorter cable, less line lose |
| Frame Support | Same | Same |
| Steel Pole | Same | Same |
| Foundation Kit | Same | Same |
| Installation Cost | High | Lower, about 30% of tradition solar street light |
| Shipping Cost | High | Lower, about 40% of tradition solar street light |
Applications
30w solar led street light used for:
Courtyard / Garden / Park / Street / Roadway / Pathway / Parking Lot / Private road / Sidewalk / Public square/ plaza / Campus / Airfield / Farm & Ranch / Perimeter Security / Wildlife area / Remote Area / Military Base
Packaging
Standard export packaging or customized according to customer requirements
