160LM/W High Lumen Output SMD3030 LED Chips UFO Led High Bay 150w For Warehouse

UFO High Bay Light
  • Product:
    led ufo lights
    ufo led high bay light
    ufo high bay light
    led ufo high bay
Description
Description

160LM/W High Lumen Output SMD3030 LED Chips UFO Led High Bay 150w For Warehouse



Industrial





Features



1. Unique Designed UFO Shape,Elegant and Compact
2. Meanwell IP65/IP67 Power Supply,50000hours Lifespan
3. High Pure Aluminum and Acrylic Lens
4. Multiple Power for Option
5. Much smaller lamp body ,50% shipping cost saved.
6. 100lm/w,110lm/w,120lm/w with Cree chip,Samsung chip and Nichia chip
7. 5 years warranty with Mean well driver
8. IP65 waterproof
9. Dimmable, RGB,Rechargeable and Sensor function for 150w UFO led high bay light are all vailable
10. Multiple beam angle:45°,60°,90°and 110°optional





Specifications



UFO High Bay Light
Item name 100W UFO High Bay 150W UFO High Bay 240W UFO High Bay
Power(w) 100W 150W 240W
Voltage AC 90-265 AC 90-265 AC 90-265
Power factor ≥0.95 ≥0.95 ≥0.95
Dimmable No No No
Lumen(lm) >12000 >19000 >28000
Color temperature Warm white:2700K-3200K & Nature white:4000K-4500K & Cool white: 6000-6500K
CRI (Ra>) >80 >80 >80
Beam angle 40°/ 60° / 90° / 120° 40°/ 60° / 90° / 120° 40°/ 60° / 90° / 120°
LED chip 154pcs LED 3030 245pcs LED 3030 360pcs LED 3030
Central light intensity(cd) 18095 24983 45850
Waterproof Rating IP65 IP65 IP65
Working Temperature(℃) -40~+50 -40~+50 -40~+50
Lamp efficiency(lm/w) 130LM/W 130LM/W 130LM/W
Light degradation rate 25000h ≤ 30% 25000h ≤ 30% 25000h ≤ 30%
Working lifetime(h) 50,000 50,000 50,000
Driver Brand Meanwell Meanwell Meanwell
Lamp body material Aluminum Aluminum Aluminum
Dimensions (mm) Φ260X178 Φ325X188 Φ400X205
Carton size(mm) 310*310*180 380*380*190 460*460*200
Net weight(kg) 2.42 3.35 5.2
Certification CE, UL, DLC, TUV, ROHS CE, UL, DLC, TUV, ROHS CE, UL, DLC, TUV, ROHS
Warranty 5 years 5 years 5 years
Installation Type Hook hanging or Chain Hanging or Mount suface Hang or Pole Hanging
Application Station, Marketplace, Factory, Workshop,Warehouse, Airport, Gymnasium Waiting room





Details



Die-casting aluminum integration design, excellent heat dissipation









Aging testing







Applications



Gymnasium ,Building,Factory,Warehouse
Supermarket,Garage Lighting,Workshop
Storage Lighting,Court,Station
Indoor and Outdoor Lighting






Packaging



Packing Material:Neutral packing with strong corrugated paper cartons,in order to withstand rough hadling under normal conditions.
QTY/CTN:1 PCS
