CE Rohs Approval Ip54 Ik10 Pure White High Bay Led Warehouse Stock Lighting

Fin Aluminum 100w 150w 200w Led Highbay Light
  • Specification:
    Power: 200w
    Input Voltage: AC90-277V
    Luminous Efficiency: 130Lm/W
    Power: 60w 100w 120w 150w 200w
    LED Chips: 3030
    Application: Warehouse/Workshop/Hall/Station
    Warranty: 3-5 Years
Description
Description

CE Rohs Approval Ip54 Ik10 Pure White High Bay Led Warehouse Stock Lighting


led warehouse lighting high bay Based on risk-free under the premise of fully insured for 3 years, pursue perfection quality lighting manufacturers, research and development by Using the exclusive patent one superconducting cooling scheme, die-casting molding zero distance and spiral tornado aerodynamic heat dissipation module system, use of international 5 star superconducting hot top made of aluminum alloy, with free maintenance, low temperature rise, low light failure, and high intensity of illumination of high performance products in the industry

Featurs

led high bay warehouse lighting fixture

1. Removable design frame, which are made of die-cast aluminium with Interactive structure ensures fast heat dissipation of the lamp body.
2. Toughened glass, reinforced anti-explosion lens, high light transmittance, effective anti-dust.
3. Unique reflector can improve lumency.
4. High quality 3030 SMD chip, high brightness, low light decay, longer service time.
5. The bracket with adjustable gear is convenient for adjust angle (0°-180°).
6. Double waterproof design, thicker water-proof rubber ring to insure better effect. Waterproof IP66 Outdoor.
7. Ultra stylish, New design.



Specification

Item industrial high bay led lighting fixtures
LED Brand 3030
LED Quantity: According to power
LED Driver MS/Meanwell
LED Color Warm white/Pure white/Cool white
Input Voltage: AC85-265V
Frequency Range 50-60Hz
Power Consumption: 100w
Optional Power: 60w 100w 120w 150w 200w
Initial Lumen: 12000-13500lm
Power Factor >90%
Lamp Efficiency >85%
Color Temperature: 3000-6500k all available
Beam Angle: 60°/120° optional
Color Rendring Index: Ra≥75
Lifespan: 50000hrs
Warranty period: 3 -5 years
Optional led chip brand Epistar
Protection Rating: IP65
Working Temperature: -­40°C ~ 50°C
Storage Temperature -­20°C ~ 65°C
Dimension: Φ500×H500(mm)
Housing Color Silver White
Surface Finished Aluminum
Certification CE,RoHS




Details

led high bay light fittings

LED high-bay light is consists of high-quality aluminum, inside are highly efficient diodes and a current driver. The increased area of the radiator fins allows for efficient heat removal, which prevents the device from overheating. Its design is made in such a way that the angle of illumination is 120 degrees and provides a large area with light. The materials from which it is made do not contain mercury and other harmful substances, so it is absolutely safe for human health and the environment.






Application

led high bay warehouse lights is installed in production workshops, hangars, warehouses, garages, staircases and other large premises. It is a powerful source of lighting that can be installed for long corridors.




Instruction for use



led high bay warehouse lights

1,Operating voltage: AC85-265v,50HZ/60HZ.Please don't work beyond the operating range and frequency range;
2,LED high bay equips with an aluminum reflector ,Please be careful to handle and store,no stacking!

Instruction for installation

1.Tighten the Ring,the ring is M20 .
2.Put the rings into the hook,and keep it stable.
3.Operating temperature is -20 °C ~ +60 ° C,storing temperature is -30 ° C - +60 ° C
4. Wiring and wiring place should be closed well to prevent leakage during installation;
5. Some corresponding water proof and leakage measures should be taken when external power cable is connected.
6.Any fire regulations can not be violated while using
7.The diagram for installation is as below:



Package

Natural package.
Carton packing with foam protection.
