IP67 Outdoor Waterproof Stadium Lighting 300W 400W 500W 600W 800W 1000W LED Flood Light

Led Stadium Light / Led High Mast Light
  • Specification:
    Lamp Power: 300W 400W 500W 600W 800W 1000W
    Item: Led Stadium Light / Led High Mast Light
    Input Voltage(V): AC 100-277V 50/60Hz
    Luminous Efficiency: 36000-155000Lm
    Narrow Angle: 25°/45°/60°/90°
    Lamp Body Material: Aluminum + PMMA
    Certifications: ETL TUV SAA DLC
Description
Description

IP67 Outdoor Waterproof Stadium Lighting 300W 400W 500W 600W 800W 1000W LED Flood Light


Description



LED Stadium Light For Stadium Lighting



Led has proved to be the trand of next generation lighting for its environmrnt-friendly,energy-saving,light efficiency,reliablity. NIN innovation LED lightings lifespan ,thus remarkable reduce the expence of lighting operation and maintance.



300W-1000W, High power LED stadium flood light solutions.
Separate LED Module, simple but generous body design, easy installations, saving much more freight.
Use Meanwell (ELG) driver and 5050 led source.
Different beam angle for different lighting appliations: 25°/45°/60°/90°/55*140°.
Application for high mast lighting, indoor / outdoor stadium sport courts, high way, park,station, port etc.




Features



Power: 300W 400W 500W 600W 800W 1000W options;
Adopt with world famous high performance Meawenll driver;
Input voltage: 200-240VAC or 100-277V. (will decide input voltage accordig to the client's country)
Lumileds SMD5050, Ra70;
Super bright, high effieciey 160Lm/W;
Beam angle: 20° is default (If need 25°/45°/60°/90° Milky cover, please leave messags)
Fin Alumium housing for the best heat sink solutions; 20% weight lighter, easy installations;
Anti-dust design,able to be with flushable cleaning;
CCT: Warm white 3000K, Natural white 4000K, Day white 5000K, Cold white: 5700K;
Working temperature: -40°C - 60°C;
Lifespan: 50,000 hours 5 years warranty;
30° single LED module adjuatable, 360° adjustable for whole LED light panel;
Salt spray resistant, corrosive resistant,processed with dedicated treatments on the heat sink, can withstand corrosive and salt intensive environments.




Specification




LED stadium light
Model Power Lumens Beam angle Lumens efficiency CCT Size (mm)
ST-FL-Y07 1000W 140000Lm 25°/ 40°/ 60°/90°/55*140° 140Lm/W 2700K-6500K 700*754*209
ST-FL-Y07 800W 112000Lm 608*754*209
ST-FL-Y07 600W 84000Lm 516*754*209
ST-FL-Y07 500W 70000Lm 700*418*209
ST-FL-Y07 400W 56000Lm 608*418*209
ST-FL-Y07 300W 42000Lm 516*388*209





Details


 1000w flood light


150lm/w CREE SMD5050
Low light decay to keep the better light performance




Independent Power Box
Independent power box solve the problem of hanging driver and bad heat dissipation


Bracket Installation
Lighting angle is adjustable, uneasy to corrode and rust, suitable for different outdoor lighting places




Lighting Solution Design
We can provide DIAlux design, DMX512, DALI, Zigbee, RDM, PWM, Sensor control system


Waterproof Test
Rainproof, Waterproof and Dustproof
Rhea stadium light works normally in harsh environments




72 Hours Aging Test
72 hours aging test before delivery
99% pass rate
strict quality control



Breakage-proof
Good packing guarantees lights from breakage










Installation



-Non-professional technicians, please do not repair or modify this product without authorization.

-Please make sure to turn off the power before installing.

-Before installing, please check whether the voltage marked on the high pole lamp is consistent with the input voltage to be connected.

-In order to ensure the service life of the product, please do not use it in a place with strong acid mist.

-Pay attention to earthquake prevention during installation and transportation.

-Install it in a flat place without vibration, no swing, no fire hazard.

-If the lamp fails, please place the lamp in one place and send it back to the company for inspection and repair.

-If the lamp body wire is damaged, please stop using it immediately.





Applications

1000w stadium light Widely used in stadium, sport field light, Tennis court, gymnasia, billboard, government lighting decoration project, landmark or building, public square and other outdoor light applications.








Packaging

300W Product size:516*388*209mm
Box Size(1pcs):59*51*25CMN.W:11.2KG G.W:12.8KG
400W Product size:608*418*209mm
Box Size(1pcs):68*51*25CMN.W:13.5KG G.W:15.4KG
500W Product size:700*418*209mm
Box Size(1pcs):79*51*25CMN.W: 15KG G.W:17.4KG
600W Product size:516*754*209mm
Box Size(1pcs):83*59*25CMN.W: 22KG G.W:25.5KG
800W Product size:608*754*209mm
Box Size(1pcs):83*69*25CMN.W:24KG G.W:26.5KG
1000W Product size:700*754*209mm
Box Size(1pcs):83*79*25CMN.W:28.5KG G.W:32KG
