LED 200W Round SMD 3030 120LM / W High Bay Light 100W 150W 200W UFO LED High Bay
Description
1. Lumileds LUXEON 3030 LED chip
2. Meanwell driver (CE,PSE,ENEC,TUV,IP65 etc...)
3. Die cast aluminum and Fireproof silicone wire.
4. Lamp lumen:120-130lm/w.
5. Hook install/Bracket optional.
6. 60°/90°/120°
7. IP65 waterproof
8. Dimming/Microwave Motion Sensor/Photocell Sensor are available
Features
Design with Patent, high quality aluminum processing technology, specail surface treatment
High lumen Lumileds LUXEON 3030 led, excellent performance Meanwelldriver, patented design, got UL CE ROHS SAA IP67 certificates
Energy savings, no PB and HG radiations, emits low heat
Easy installation and maintenance, IP65 design
Hook type/bracket type optional
International operating voltage AC90-305V/180-480V
Built-in 3 in 1 dimming function (1~10VDC, PWM signal, or resistance)/Microwave motion sensor
Specifications
| Product Name |
UFO LED High Bay Light |
| Item NO. |
100W/150W/200W |
| Optical Data |
Electrical Data |
| LED Type |
Lumileds LUXEON 3030 |
Power Supply |
Meanwell HBG/HLG |
| LED QTY |
133pcs, 210pcs, 315pcs |
Input Voltage |
AC 95-305V |
| System Efficacy |
130LM/W(CCT5000K) |
Power Frequency |
50-60Hz |
| Luminous flux |
13000LM(5000K) 19500LM(5000K) 24000LM(5000K) |
Output Current |
2.0A(Constant Current) 3.15A(Constant Current) 4.0A(Constant Current) |
| CCT |
3000K/4000K/5000K/6000K |
Output Voltage |
DC28.8-48V |
| Beam angle |
60/90/120° |
Power Efficiency |
>93% |
| CRI |
Ra>80 |
Power Factor |
>0.96 |
| System Efficiency |
>90% |
THD |
<15% |
| Other Parameter |
| System Power |
100W±3W,150W±5W,200W±8W |
Junction Temp |
<70℃(Ta=30℃) |
| LED Power |
96W±3W,146W±3W,196W±3W |
Storage Temp |
-40~70℃ |
| Shell Material |
Aluminum |
Operating Temp |
-20~55℃ |
| Life Span |
>50000H |
|
|
| Optional Information |
| Install Method |
Loop Hanging/Ceiling Mounting/Wall Mounting |
| Intelligent Control |
DALI Control/PWM/1-10V DC Dimming |
Details
Dimension
Applications
1. Conference/Meeting rooms, Classrooms
2. Offices, Hospitals, Factories , Supermarket , Disco , Karaoke
3. Hotels, Offices or other Commercial Complexes
4. Residential/Institution Buildings
5. Places where energy saving and high color rendering index are needed
6. Replacement bulbs for general ligthing , especially for museums
Packaging
| 100W |
1 PCS/CTN |
320*320*205MM |
N.W.: 3.4KG |
G.W.: 4.4KG |
| 150W |
1 PCS/CTN |
350*350*210MM |
N.W.: 4.7KG |
G.W.: 6.0KG |
| 200W |
1 PCS/CTN |
425*425*220MM |
N.W.: 6.5KG |
G.W.: 8.0KG |
