LED linear lighting fixtures 2ft 4ft 8ft dimmable architectural up and down indoor suspended lighting fixture

LED Linear Light Aluminum Pendant Lighting
  • Spec:
    LED Linear Light Aluminum Pendant Lighting
    Up Or Down / Up And Down
    AGT Lifud UL Listed
    Black / White / Silver
Description
Description

LED linear lighting fixtures 2ft 4ft 8ft dimmable architectural up and down indoor suspended lighting fixture


Features


linear led pendant light



Energy Saving.
LED Chip: Epistar 2835SMD, passed LM 80
Different finish color optional(silver/white/black)
High power, different length optional
Can be dimmable(Triac, 0-10V, Dali dimmable optional)
CE and ROHS Approval.
Test Report and IES File can be provided.





LED Linear Light is a sleek linear system,bringing high-quality LED illumination,with guaranteed compatibility between LED fixture, driver and controls.According to the installing ways,they are devided into 3 kinds:surface mounted linear recessed linear and pendant linear light.The LP06 Series linear light is full round type which designed as the suspensed pendant light.







Specification

led linear suspension lighting



Specification
Item No
UP Indirect and Down Direct
Product Size
75*54mm
Length
890mm
IP Level
IP40
Aluminum Channel
T5 6063 Al
Cover Material
PMMA/PC
Cover Type
Milk
Accessories
Suspension Wires
Color
Silver/Black/White
Customized Color
Color Anodized/Powder Coated/Spray Painting
Install
Suspended
Application
All Kinds of Indoor Projects
Warranty
3 Years
Certificates
CE ROHS





Details

linear led light fixtures


High quality Linkable LED linear light for office/Architectural/school/display centers/ shops/stores.
It contributes to comfortable, healthy workplaces by lighting the task, face and space.
Producing soft light with invisible LEDs.
Suitable for dry/damp location.
Materials: 6030 aluminum profile+PC cover


Size: 600mm(L)*55mm(W)*70mm(H) 2ft
Power: 20W
Lumens: 110lm/w
Input voltage: 100-270VAC
LED driver: internal flicker free
LED type: SMD2835
Color temperature: 2700K 3000K 3500K 4000K 5000K


Installation: Surface-mounted/Suspended with hanging cable.
Lights can be joined together in a seamless continuously line but can not do continuously running electrically.



Construction
Die formed, 22 gauge, cold rolled steel designed for high strength.End caps snap in for easy installation and maintenance.
In addition, the end cap can be used as a joint aligner for continuous row mounting.


Light Source
Using the energy-saving highlighting 2835 SMD LED light source.

Distributed LED array in a variety of lumen output packages.

LED color is available in 2700-6500K. Module is replaceable.


Mounting
Luminaires may be surface mounted or suspended, individually or in continuous row. Fixtures easily snap
together for long continuous rows.


Driver
Using isolation constant-current drive power, is the guarantee of security, stability and no flicking.





Applications

LED linear lighting can be Use in Airport, Bathroom, Bathroom Room, Bedroom, Car Park, Church, Cinema, Gallery, Garage Hospital, Hotel, Kitchen, Meeting Room, Museum, Office, Restaurant, School, Shopping Mall, Sitting Room.







Installation

Seamless and linkable.
1. Suspened wire
2. Ceiling mounted
3. wall mounted
4. Recessed




Packaging

LED Linear Lighting Standard export packaging or customized according to customer requirements
