Meanwell Driver IP65 Indoor Outdoor Workshop 100 150 200 Watt Linear LED Highbay Light
Most cost-effective LED Linear High Bay lights, with CE, ROHS, NOM, EMC, LVD, TUV, DLC, SAA certificates, are widely used in warehouses, tunnels, parking lots, planting growth. We support sample order and offer 3 to 5 years warranty.
Product Description
led linear high bay light
1.High Power,50w / 100w / 150w / 200w / 250w / 300W are also available
2.Save 80% more energy compared with traditional lighting fixtures
3.Unique structure for excellent heat dissipation
4.High quality,long life span>60000hrs
5.High brightness,low consumption,green for environment
6.warehouse, workshop, supermarkets, exhibition room, hall, toll station, gas station, residential areas, industrial areas, etc.
Specification
|
Linear LED Highbay Light
|
|
| Wattage | 100W |
| Voltage | AC 200-295V, 50/60Hz |
| Certificate | CE, RoHs |
| Lumen | 13000±5% |
| Power Factor | >0.95 |
| Life Time | >50000 Hours |
| Size | 650*165*195MM |
| Chip | 3030 |
| CRI: | 80 |
| Color Temperature | 2700-6500K |
| Beam Angle | 60 degree 140*80 degree |
| Storage Temperature | (- 20 ~ + 65 ) Degrees Celsius |
| Operating Temp | (- 40 ~ + 65 ) Degrees Celsius |
| Warranty | 5 years |
| MOQ | 1PCS |
| Driver | Meanwell ELG |
Details
led linear high bay light
LED Chip & Lens
LED: SMD3030 led, LM-80 standard,
High lumen 110-140lm/w
Lens: PC material
30° / 60° / 90° / 80*155° degree beam angle
Driver
Original Taiwan Meanwell HLG series driver,
7 years warranty
IP65 waterproof
Heatsink
The housing is extrusion aluminum production process,better heat dissipating performance,and more slim,more light,more design popular,much more LED chip quantity to make make light higher lumen effeciency.
slim and light design housing could save your shipping space and cost.
Perfect lighting cover
This is lighting distribution for your kindly reference
Our Linear high bay light with 30° / 60° / 90° / 80*155° beam angles, meet different using enviornment.
Factory
Applications
led linear high bay can used in
1 Warehouse lighting
2 Workshop, Steel Mill lighting
3 Supermarket lighting
4 Exhibition Halls lighting
5 Gym/ Stadium lighting
6 Gas Station lighting..
Packaging
Standard export packaging or customized according to customer requirements
