Motion Sensor 40W 50W 60 Watt Module Inductive Integrated Solar Lamp Led Street Light
Features
All In One Led Solar Street Light
Design Principle:
It integrates solar cells, lithium batteries, LED light sources, human body infrared sensors, solar energy system controllers, aluminum frames and mounting fixtures. Also optimizing the electronic circuits, the advantage is easy to transport, installation, replacement of each parts, convenient maintain etc..
Operating Principle:
Through the light control and PIR sensing / Constant working mode, the solar panel receives light during the day to charge the lithium battery. When the controller detects that the input voltage of the solar panel is low , the controller starts to supply power to the LED light source. When the input voltage of the solar panel is recover, the controller will cut off the output power of the LED light source automatically, so as to achieve the purpose of light on at night, light off at day automatically. Use remote control
Specifications
| Item No. | all in one solar street light | ||||||
| Power | 30W | 40W | 50W | 60W | 80W | 100W | 120W |
| Solar Panel | 18V/50W | 18V/65W | 18V/70W | 18V/80W | 18V/100W | 18V/130W | 18V/140W |
| LifePO4 Battery | 12.8V/27AH | 12.8V/28AH | 12.8V/36AH | 12.8V/42AH | 12.8V/57AH | 12.8V/63AH | 12.8V/72AH |
| Mounting Height | 6-7M | 7-8M | 5-7M | 5-8M | 6-9M | 7-10M | 7-12M |
| Lighting Mode | Night Sensor + Microwave Motion Sensor + Remote Control | ||||||
| Color Tempreture | 6000K ~6500K(customized) | ||||||
| Solar Charging Time | 6 hours | ||||||
| Light effect | 170LM/W | ||||||
| Cloudy/Rainy days | 3~7 Cloudy/Rainy days | ||||||
| Material | Aluminum | ||||||
| Waterproof | IP65 | ||||||
| Life Time | 100000hours | ||||||
| Working Tempreture | -25°C to 65°C | ||||||
| Certificate | CE / ROHS / IP65 | ||||||
| Warranty | 3 Years | ||||||
Details
all in one solar led street light
sign for working of LED light
sign for solar panel charging
sign for battery charging
working temperature - 20°C to + 70°C
IP 66 : Independent IP66 battery box design ,more safe. can work under water
Easy replace battery and control , do not neet to teardown
Application :Widely used in Rural road, Courtyard, Villa, Park, Square, Farm, School, Factory, Slow lane etc...the places where need outdoor lighting and with enough sunshine.
1.long life,high brightness,maintenance-free
2.integrated,easy to install and transport
3.light sensor automatically control the work of LED lights
4.High efficiency and energy saving
5.Human intelligent sensor system can save energy and reduce energy consumption
6.Be installed in gardens,roads,mining areas,parking areas etc.
Applications
All in one integrated solar street light can be application at :
Widely used in Rural road, Courtyard, Villa, Park, Square, Farm, School, Factory, Slow lane etc...the places where need outdoor lighting and with enough sunshine.
Factory
Packaging
Solar led street light :
Solar panel:carton package and pallet
Battery:carton package and pallet
Controller:carton package and pallet
Pole:bubble wrap
Fixture:carton package and pallet
Why Choose Us
Q1. Can I have a sample order for led solar light?
A: Yes, we welcome sample order to test and check quality. Low MOQ, 1pc for sample checking is available.Mixed samples are acceptable.
Q2. What is your terms of payment?
A:Usually,we accept T/T,irrevocable L/C at sight.For regular orders, Terms of payment 30% deposit,full payment before delivery the goods.
Q3. You are manufacturer or trading company?
A:We are factory. Welcome to visit our factory at anytime.
