| LED Linear High Bay Light | ||||
| Certification | ENEC,TUV,SAA,CB,UL,CUL,FCC,DLC4.2 Premium, IK10, IP66 | |||
| Product No. | MS-HBL-C-50W | MS-HBL-C-100W | MS-HBL-C-150W | MS-HBL-C-200W |
| Dimension L*W*H | 350*172*126mm | 634*172*126mm | 917*172*126mm | 1200*172*126mm |
| Power(W) | 50W | 100W | 150W | 200W |
| Input Voltage(V)-TUV SAA | AC100-240V 50/60Hz | |||
| Input Voltage (V)-UL DLC | AC100-277V or AC277-480V 50/60Hz (Optional) | |||
| PF | >0.95 | |||
| CRI(Ra) | >80 | |||
| CCT | 3000-6500K | |||
| Luminary EER (lm/w) | 140Lm/w ~160lm/w | |||
| Luminous (lm) | 11,200lm | 16,800lm | 21,000lm | 28,000lm |
| Beam Angle | 120° | |||
| Function option-UL | 1-10V & Dali Dimming | |||
| Function option-TUV | 1-10V & Dali Dimming | Emergency (1,2,3hours) | Microwave Sensor | |||
| Installation | Suspension | Ceiling-mounted | Wall-mouted angle adjustable | |||
| Guarantee | 5 years warranty | |||
Details
Housing for LED Linear high bay light:
High quality steel housing, rust and oil removed, under anti-rust treated and rust proof for 8-10 years under normal application, with white powder coating.
Diffuser for LED Linear high bay light:
Polycarbonate, Acrylic LED Diffuser Specially for LED.
LED type for LED linear high bay light:
It uses Led SMD 2835.
Electrical for LED Linear high bay light:
Lifud or Famous logo standard driver or Dali /Dimmable driver.
Mounting for LED Linear high bay light:
Suspended mounting by chain or stainless steel cable.
Main applications:
Garege / Warehouse / Gym / Manufacturing place / Super-market / Hyper-market / Parking area / other public places.
Applications
industrial led linear high bay light for warehouse widely use in Factory,Workshop, Warehouse, Logistics Center, Exhibition Hall, Stadium, Gas Station, Supermarket and etc.
