Smart Outdoor Lithium Battery Independent Solar Panel Integrated Solar LED Street Light

Integrated Solar LED Street Light
  • Product:
    integrated solar street light
    integrated solar led street light
    integrated solar light
Description
Description

Smart Outdoor Lithium Battery Independent Solar Panel Integrated Solar LED Street Light





Description



As a outdoor lighting fixture, the Solar Light is powered by solar energy and designed to offer outstanding quality by utilizing A-class LED beads, integrated optical LED lens, high efficiency mono solar panel, powerful lithium battery, self-developed MPPT controller and patent bluetooth APP system.





Operation principle


The Solar Light is a revolutionary product by utilizing Photovoltaic effect. It is designed to constantly absorb solar energy in daylight and convert to electricity, the intelligent controller could precisely control the charge, discharge and well preserve electricity into the lithium battery. And start to illuminate, which is powered by the lithium battery, once the illuminance of ground reduced to 15 lux in night time, or solar panel voltage drop to 5V below. The intelligent controller not only protects the battery from over-charging,over-discharging, but also can control the light switch-on,the time of switch-on and optimize the brightness effectively according to the





Features



integrated solar street light



1 Integrated design, built-in lithium battery, independent solar panels.
2 30W 40W 50W 60W 80W available
3 Elegant Integrated Design,Aluminum alloy case.
4 Mono-crystalalline & Replacable Lithium battery,Simple installation.
5 Intelligent lighting control system:
1) Customizable lighting time: 1-15 lighting hrs & 1-5 lighting periods according customer choice;
2) Intelligent lighting brightness: The controller will control the brightness of the LED lamp according to the battery level;
3)Light sensor: AUTO ON/OFF ; PIR motion sensor: 7-10m detecting distance,120°wide detecting angle.
6 Support 5-7 cloudy or raining days' lighting







Specifications



solar powered led street light with auto intensity control




Integrated Solar LED Street Light
Type
30W
40W
50W
60W
80W

Panel
Power
100W/18V
120W/18V
150W/18V
200W/18V
240W/18V
Material
Mono crystalline silicon

Lithium
Capacity
380WH
460WH
610WH
690WH
880WH
battery
Charge cycle times
1500 times


Lamp
Luminous flux
5800-6100lm
7500-7700lm
9100-9300lm
10000-11000lm
11000-12000lm
head
Light output
30W
40W
50W
60W
80W

Elevation angle
17° (attention to Dialux use)

Lifespan
50000hrs


System
Control voltage
5V
Beam angle
X-axis: 158° Y-axis: 62°
Light distribute
Batwing lens with polarized light
Install
Mounting height
7-12m





Details



Integration design


1. Integrate the solar panel, led body, battery and controller into whole system. Easy to transport, install and maintain.

2. Strong mechanical load capacity, entire module certified to withstand high wind and snow loads



Structure design


1. Solar panel can be adjustable manually in vertical and horizontal direction, ensure
the maximum efficiency of solar energy

2. Solar panel looks like an umbrella to protect battery from high temperature and
extend the lifetime. Perfectly solve heat dissipation


Industry design


Originating from the design of the horse nape, this solar street light adopts a streamlined structure and has the unique beauty to break the mold of sameness





Excellent LED chip


1. Color temperature: 3000-6000K
2. 180lm/w high luminous efficiency
3. Low light decay and long service life
4. More energy saving than competitors
5. Redeveloped based on USA Bridgelux chip
6. Works normally at high or low temperatures
7. Professional light distribution with patented lens




Durable lithium battery


1. Lifespan: 8-10 years
2. Fast charging speed
3. No pollution and stable
4. High temperature resistance
5. LiFePO4 battery with high capacity
6. >2000 times charge & discharge cycles
7. Fully sealed construction, maintenance free



Efficient solar panel


1. 20-25 years lifetime
2. tempered glass cover
3. 150W-240W panel power
4. Certified by TUV, CQC, etc
6. A grade high efficiency solar panel
5. Increase charging efficiency by 25%
7. Excellent performance under low light environments





Core technology



MPPT Technology
The conversion efficiency of solar system are fully increased, effictively shorten the 20% charge time


170lm/w high light efficiency
Consume less power to output higher lumen, which is very energy-saving. At the same time, it increase light brightness by 75% compared with competitors, which is very technological



Professional light distribution
Embedded with Road Smart self-developed patented lens, bat-wing & polarized lighting strategy, wider lighting area, more comfortable and uniform light brightness



Long Last lighting with Intelligent Power
With patented software algorithm, system automatically plan the discharge power based on local weather, and achieve the perfect balance of brightness and discharge time. The bright lighting can last for more than 15 rainy days



8 Years Lifespan with BMS
Patent software and hardware technology to average the charge and discharge current on each battery cell, improve charge cycle times, extend the service life for more than 8 years


Motion sensor control
Embedded with microwave motion sensor, which is the latest generation sensor technology, automatically and accurately adjust light luminance according to ambient movement



Multiple working modes with dimmer
Remote control and reset different modes for street lighting. Light control, time control, motion sensor and light control, motion sensor and time control, demo mode, off mode


Three light indicator
Fast status diagnosis, through charging indication,Battery indication and Load indication, quickly judge the light status without any tools









Applications



Solar integrated street light have been successfully applied in 120 countries' projects, which are projects for parking lot, ferry, square, road, street, avenue, plaza, square, boulevard, freeway, highway, motorway, etc
