Smart Round Plaza All In One Solar Street Courtyard Light Integrated PIR Sensor

All In One Solar Street Courtyard Light
  • Product:
    All In One Solar Street Courtyard Light
Description
Description

Smart Round Plaza All In One Solar Street Courtyard Light Integrated PIR Sensor





Description



The design of the solar street light all in one comes from the inspiration and power of the universe, combined the best energy saving parts---solar panel, led lamp and special battery. With the help of the controller and PIR sensor, it realizes the functions of high brightness with low energy, long lifespan and free maintenance. At the same time, it is very convenient to ship and install. It is one of the best patent products of our company




Features


all in one solar street courtyard light



1. Wireless and Integrated Design, no cable, easy installation and maintenance;
2. Multi installation way, lamp pole can be lodal materials, leke wall, iron column, tree trunk, bamboo, etc
3. Used of long life and high capacity lithium iron phosphate battery with theoretical service life 5-8 years, working well in 70℃ environment, long service life, ensure the service life od the entire product.
4. Only use A battery core for all of our products. Battery is the key material for solar street lights.
5. Our standard configration design can make sure lamps working normally during 3 continous raining days. Normal working time: 10-12 hours each night.
6. All models are with light-sensor: Lamp turn ON automatically in night, and turn OFF automatically in daylight.



Specifications



15watt 20watt 30watt Led Solar Garden Light



All in one solar street light UFO-15W Model:MS-UFO15W
Solar panel Max Power 18V/25W(High efficiency monocrystalline silicon)
Life Time 25 years
Battery Type lithium battery(12V8AH)
Life Time 5-8 years
Led lamp(NO Sensor) Max Power 9V/15W
Led chip brand USA bridgelux
Lumen(LM) 1500-1650lm
Life Time 100000hours
Lamps material of main aluminium Alloy
Charge time 8hours (with enough strong shine)
Discharge time More than 20hours
Certificate CE/ROHS/IP65
Warranty period 3 years
Packing& Weight Product Size Diameter 510mm,height 230mm
Product Weight 8.2KG
Carton Size 570*570*280mm(lamp + accessories)
Quantity/Carton 1set/carton
GW.for Carton 10KG



Details


Integrated Solar street light with lithium battery is an integrated of solar panel,LED light,lithium battery,controller and lighting housing,Daytime solar panel turn sunlight into electricity,with intelligent controlled technology store energy the daylight.During the night when the brightness decrease,solar panel working voltage less than 4V,the sensor will work automatically controller by intelligent induction module.lithium battery turn the electricity to light.Lithium battery discharge to the dawn of illumination increased, the solar panel working voltage is more than 4V, the charge and discharge controller action, lithium battery discharge (off the lights)










How to unlock the working system and use remoter?



When the solar panel detect strong enough sunshine, the system would start work automatically with default value.

Remote Control (Remoter) can Turn On/Off the light, Adjust the brightness of the light.



How to install?



Very easy to install, just screw on the light to the pole by supplied screws



Warning



1.Keep the device away from fire and oil in order to avoid any fire or explosion.

2.Any severe shock to the light is not recommended.

3.No one except professional technicians should attempt to disassemble the light in order to avoid damaging the light.




Applications


Solar street light with inbuilt battery are widely used around the world of highways, streets, courtyards, parks, scenic spots, outdoor parking lot, etc.



Packaging

Product size:(D)510mm*(H)230mm, NW 8.2kg .
Packing Size: 570mm*570mm*270mm, GW 10kg
Quantity for 20GP/40GP: 330pcs/638pcs
