Warehouse Lighting Indoor Factory 60 80 100 150 200 250 Watt Industrial LED High Bay Lights

Industrial LED High Bay Lights
  • Spec:
    60W/100W/150W/200W
    AC90-265V
    Brideglux
    3000K/4000K/6500K Optional
    60/90/110 Degree
    50000 Hours(<10% Light Failure)
Description
Description

Warehouse Lighting Indoor Factory 60 80 100 150 200 250 Watt Industrial LED High Bay Lights





MINSENS® LED highbay lights are designed for simplicity,elegance and practicality.



1.Using imported chip, LED encapsulation structure optimization, to achieve low light failure, high photosynthetic efficiency, energy conservation and environmental protection advantages.
2.Power supply key components adopt world brand, optimize the structure of heat dissipation, can guarantee the life of lamps.





Featurs



industrial high bay led light fixtures



1 1060high purity aluminum reflector,anodized and polished the fin structure is uniformly illuminated, significantly improve light output efficiency.
2 Both milky white and transparent PC are available,high light transmission,flame retardant,anti-oxidation. The ratating buckle is fixed for easy installation.
3 The curved heat dissipation design is remarkable,increasing the heat dissipation area.
4 Optional multi-angle reflector,effectively improve the light utilization requirements of different environments.





Specification



led high bay factory lights
Product Name led high bay factory lights
Power 60w/100w/150w/200w
Light Source SMD3030 chips
Color Temperature 3000K/4000K/5000K/6000K
Luminous Flux 105-113 lm/w
CRI >80 or >90
Beam Angle 60°/90°/110° (by different lampshade)
Driver SOSEN Driver(TUV/SAA/UL/BIS/CCC Certified)
Meanwell Driver
Input Voltage 90-305VAC
PC Cover(on top of chips) Clear/Frosted Optional
IP Rating IP54
Warranty 5 years
Resist Lighting Surge Voltage 4KV





Details



led high bay light fixtures



1. CE ROHS TUV Certified
2. Low power consumption, high luminous efficiency and energy saving
3. Easy to install and use.
4. High efficiency,high accuracy, and long-life constant current LED power supply, the efficiency can reach as high as 91%
5. No risk of mercury emission, No UV or RF interfcernce, No mercury or lead, environmental protection
6. High heat conductivity, low luminous decay, pure light color and no ghosting.
7. Integrative design for heat sink and housing; The LED is closely connected to the surface. The heat From the LED is removed through the heat dissipation wing and also by air ventilation.
8. The surface is passed through anodic oxidation treatment. Its structure is compact and beautiful.
9. Using high quality aluminum for production, fine workmanship, elegant appearance
10. Recommend the use of warm white and white. Long life span with 50,000 hrs.
11. PC Cooler heatsink use the HDT Technology:
12. Pure Copper heatpipes directly touch the heat souce which could quickly transer heat to the heatsink with the heat transfer rate over 200 times of the aluminum radiator.














Application



high power led high bay lights can be used in Workshop, warehouse, highway toll station, gas station, supermarket, exhibition hall, gymnasium and other lighting places.







Installation Process



industrial high bay lights



1. Turn off power supply to avoid the risk of electrical shock.
2. Proper grounding is required to ensure personal safety.
3. Make certain power is OFF before starting installation or maintenance.
4. Do not recess the fixture.
5. A qualified electrician should do all work.
6. DO NOT TOUCH THE LED CHIPS. DAMAGE MAY OCCUR.







Package



led high bay light


1: 1pcs/ctn, normal packing by carton, also can be packed under the customers' requirement.
2: If it is fragile, we will provide wooden case to protect them.
3: If ship by sea, shipping trays can be offered for customers.
