Waterproof IP65 Industrial High Bay Lights 400w 120lm/W 5 Years Warranty
Featurs
216 °adjustable angle
13 flexible positions makes project angle can be adjusted within 216 °.
Copper heatpipe
By riveting the heatpipe to the fins,the heatpipe can conduct heat rapidly from chips bottom to the
fins,great lower down the temperature of light source,extending its life span.
Respirator design
Waterproof design, eliminating mist, avoiding condensation,improving quality,extending the life span.
92% reflective rate
Reflector's beam angel 62 °,Reflective rate could reach up to 92%.
Specification
| Power: | 400w |
| Material: | Aluminum and tempered glass |
| Type Of Chip: | 1w-3w High Power LED Chip |
| Brand Of Chip: | CREE/Bridgelux |
| Luminous: | 48000LM |
| Color Temperature: | 2700 ~ 7000K |
| CRI: | Ra ≥ 80 |
| Beam Angle: | 45° , 90°,60° |
| IP rating: | IP65 waterproof |
| Total Harmonic Distortion(THD): | <15% |
| PF: | >0.95 |
| Working Life: | ≥ 60000 hrs |
| Avaliable Power: | 100w,120w,150w,200w,300w,400w,500w |
| Warranty: | 5years |
| Dimensions | |
| Finishing Color: | Black;Silver |
| Wire connection: | L(Brown);N(Blue);G(Green/Yellow) |
| SHAPE: | Rectangle |
| Weight: | 12.3 Kg |
| Size: | 459*246*374mm |
| Adjustment bracket: | 0-216° |
| Package Size: | box size: 480*280*530mm |
| 1pcs/carton; CBM:0.07m³ | |
| Work Environment | |
| Input Voltage: | AC90-305V/480V,50-60Hz |
| Operating Temperature: | -40~ 70°C |
| Application: | Gymnasium, Sports Stadium Lighting; Building, Billboard Lighting; |
| Gas Station, Garage Lighting; Park, Garden Lighting; Workshop, | |
| Factory Lighting; Warehouse, Storage Lighting; Yard, Square Lighting; | |
| Road,Highway Lighting;Station,Dock Lighting etc. | |
| Recommend mounting height: | 8m-18m |
| Recommend pole Distance: | 20m-30m |
Details
Application
Gymnasium, Sports Stadium Lighting; Building, Billboard Lighting;
Gas Station, Garage Lighting; Park, Garden Lighting; Workshop,
Factory Lighting; Warehouse, Storage Lighting; Yard, Square Lighting;
Road,Highway Lighting;Station,Dock Lighting etc.
Production line
Package
Standard packing, Neutral export packaging.
